What do the different colours of the status light indicator on Beosound A9 5th Gen mean?


Product status

Light indicator placed on left side of the volume controls when seen from the front

OffSwitched off
White (solid)  Connected to network, ready for use
White (pulsing)Paused / muted
White (flashing) Starting up
White (flashing quickly) Room compensation measurement in progress
Blue (solid) Bluetooth pairing successful - visible for 5 seconds
Blue (pulsing) Bluetooth pairing mode
Red (solid) Product error, please contact the support team for assistance
Red (flashing) Temporary product error, e.g. overheating
Orange (solid) Not connected to a network
Orange (flashing) Ready for network setup
Orange (pulsing) Connecting to network
Green (pulsing) Software update in progress





Microphone

Light indicator placed on right side of the volume controls when seen from the front

OffMicrophone muted
White (solid)  Microphone enabled
