| Event | Light indicator on Beosound Core | |
| Starting up | Pulsing white | |
| Network standby mode | Dimmed white | |
| Product ready for wireless setup | Pulsing amber | |
| Wi-Fi status | Connected - Good signal strength | Solid white |
| Connected - Medium to poor signal strength | Solid amber | |
| Product is unconfigured | Solid blue | |
| Network error | Solid blue for 5 min - then dimmed blue | |
| Bluetooth pairing | In progress (only for products which are not set to “Always Open”) | Flashing blue |
| Successful | Transition from blue to Wi-Fi status (in 2 seconds) | |
| Pairing failed | Transition from red to network status (in 2 seconds) | |
| Bluetooth active source | For the first 5 min | Solid blue |
| Bluetooth source paused | Solid blue | |
| Changing to other source | Change from blue to network status | |
| Disconnecting Bluetooth | Change from blue to network status | |
| Idle after 5 min | Dimmed blue | |
| All other active sources | Network status will be shown | |
| Software updating | Pulsing red | |
| Factory reset triggered | Red - Quick flash once then off | |
| Error | Product/software | Off |
| Hardware overheating | ||
