Beoplay Portal have two light indicators; one to show the status of headphones and one for showing the status of the battery:
|
Product indicator (next to on/off and Bluetooth button) |
|
|
White (Solid) |
Switched on |
|
White |
Switching off (manually or automatically after no signal for 15 minutes) |
|
Blue (Solid 5 seconds) |
Bluetooth connected / disconnected |
|
Blue (Flashing) |
Bluetooth pairing mode (ready to pair with a device) |
|
Red (Solid 5 seconds) |
Bluetooth pairing failed |
|
Red (Solid) |
Microphone muted |
|
Red (Flashing 5 seconds) |
Factory reset |
|
Green (Flashing) |
Software update ongoing |
|
Battery indicator |
|
|
Orange (Flashing) |
Battery charging |
|
Green (Solid) |
Charging complete |
|
Red (Flashing) |
Charging error |
|
Red (Solid) |
Battery low (2 - 10% charge) |
|
Red (Flashing) |
Battery critically low (below 1% charge) |
