Installation Guide - Beosound Stage and supported LG screen in integrated setup

Besides the Beoremote One BT remote control, you will need:

- LAN connection cable from Beosound Stage to the LG TV screen* for communication and control.

- HDMI cable from Beosound Stage to the HDMI eARC input in the TV screen. HDMI cable is included in the accessory box of Beosound Stage.

Steps:

1. Go through the first-time set up on the LG screen. Ensure that the TV is connected to the network.
2. Go to Connection menu in the TV, then HDMI Device Settings and disable "Auto Device Connection" to allow Beoremote One to control your HDMI-connected device to Beosound Stage.
3. Now that you are ready to set up your Beosound Stage, on your mobile device, open the Bang & Olufsen app and add Beosound Stage as a new product, go through the first time setup. This will guide you through the physical installation, HDMI cable and the network connection.
4. Connect the LAN cable between Beosound Stage (marked as Ethernet TV input) and the TV (marked with LAN).
5. Go to the TV LG content store, install and launch the Bang & Olufsen app. Follow the on-screen instructions. You will be asked to restart the TV, turn it on with the LG remote.
6. Pair your Beoremote one with your Beosound Stage. You need to set both the Beosound Stage and Beoremote One in pairing mode.
   - Beosound Stage: Long press (1.5 sec.) on the Bluetooth button to open for pairing.
   - Beoremote One: Press ‘List’ ‘Settings’ ‘Pairing’ ‘Pair’.
   - If your Beoremote One is new, you will have to select the language first and then it will be automatically in pairing mode.
7. You are now ready to control your Beosound Stage and LG OLED TV* with Beoremote One.

*The following LG screens can be used with Beosound Stage and controlled by Beoremote One:

Please note, if in the future you want to connect your Beosound Stage to another TV, you will need to do a factory reset to your Beosound Stage. Please click here to learn how to reset.
