Beosound 1 has two light indicators which are used for multiple functions.
The Status indicator is positioned on top of the Beosound 1 in the middle of the touch plate:
|
White (shortly) |
Switched on |
|
White flashing slowly |
Charging battery |
|
Red solid |
Battery capacity between 0 – 10 % |
|
Red flashing fast |
Battery capacity below 2% Hardware error |
Note that when battery capacity drops below 10%, the volume is lowered. When below 2%, Beosound 1 switches off.
You can see the battery capacity and the state of the battery in the Bang & Olufsen app. Select the Beosound 1, go to "Product settings", "Configure", "About" and then "Status".
You can download the Bang & Olufsen app here
The Lens indicator is positioned in the middle of Beosound 1 directly under the touch plate.
|
White flashing slowly |
Starting up |
|
White solid |
Connected to network, ready for use |
|
Blue flashing fast |
Bluetooth pairing ongoing |
|
Blue shortly |
Bluetooth connection successful |
|
Red shortly |
Bluetooth connection unsuccessful |
|
Blue solid |
When not configured to network and not in configuration mode |
|
Amber flashing fast |
Ready for network setup |
|
Amber flashing slowly |
Connecting to network |
|
Amber solid |
Wireless connection of medium quality |
|
Red solid |
Wireless connection of poor quality |
|
Red flashing fast |
Failed to connect to a wireless network |
Status and lens indicators simultaneously
|
Red, flashing once |
Factory reset |
|
Red flashing slowly |
Updating software |
If the 4 status light indicators on your Beosound 1 GVA version are red, the voice assistant microphone is disabled.
