Can I connect my Beolab 18 or subwoofer to non-Bang & Olufsen products?

Yes, you can connect your Beolab 18 or subwoofer to non-Bang & Olufsen products.

The speakers/subwoofer must be connected to the line output (volume controlled line out) of the amplifier. Different kinds of cables are required depending on the type of sockets on your speaker/subwoofer, see the table below. The cables are available from your Bang & Olufsen retailer. You can find your nearest retailer here.

If there is no Line-in on the speakers/subwoofer, and a Power Link connection is required, then use a Line/Power Link adaptor cable.



Loudspeaker Sockets
Beolab 11  Power Link
Beolab 5  Phono / RCA / Cinch
Beolab 9  Power Link
Beolab 8002  Phono / RCA / Cinch
Beolab 6002  Phono / RCA / Cinch
Beolab 3  Power Link
Beolab 4000  Power Link
Beolab 4  Mini-jack
Beolab 2  Line adaptor
Beolab 12  Power Link
Beolab 10  Power Link
Beolab 14  Power Link
Beolab 15  Power Link
Beolab 16  Power Link
Beolab 17  RCA (R-input-L) / Optical
Beolab 18  RCA (R-input-L) / Optical
Beolab 19  RCA (R-input-L)
Beolab 20  RCA (R-input-L) / Optical
Beolab 50  RCA (R-input-L)  (2 x RCA)
 Optical
 S/P-DIF (1 x RCA)
 USB-B Audio
Beolab 90  RCA (R-input-L)  (2 x RCA)
 Optical
 S/P-DIF (1 x RCA)
 USB-B Audio
 XLR

You can also connect Bang & Olufsen passive speakers to non-Bang & Olufsen products. This type of speaker needs to be connected to any standard power amplifier output.


Loudspeaker  Sockets
Beovox 1  Speaker terminal
Beovox 2  Speaker terminal
