Beosound 2 has two light indicators which are used for multiple functions.
The Status indicator is positioned on top of the Beosound 2 in the middle of the touch plate:
| White (shortly) | Switched on |
| Red flashing fast | Hardware error |
The Lens indicator is positioned in the middle of Beosound 2 directly under the touch plate.
| White flashing slowly | Starting up |
| White solid | Connected to network, ready for use |
| Blue flashing fast | Bluetooth pairing ongoing |
| Blue shortly | Bluetooth connection successful |
| Red shortly | Bluetooth connection unsuccessful |
| Blue solid | When not configured to network and not in configuration mode |
| Amber flashing fast | Ready for network setup |
| Amber flashing slowly | Connecting to network |
| Amber solid | Wireless connection of medium quality |
| Red solid | Wireless connection of poor quality |
| Red flashing fast | Failed to connect to a wireless network |
Status and lens indicators simultaneously
| Red, flashing once | Factory reset |
| Red flashing slowly | Updating software |
If the 4 Status LEDs on your Beosound 2 GVA version are red, this means that GVA/microphone is disabled.
