Light indicator

Status LED (on top of the product in the middle of the touch plate):


White (shortly) Switched on. When operated
White flashing slowly Charging the battery
Red solid The battery capacity between 0 – 10 % (needs charging)
Red flashing fast The battery capacity below 2% (will soon switch off) Hardware error


Note that when battery capacity drops below 10%, sound volume is lowered. When capacity drops below 2%, Beosound 1 switches off.



Lens LED (in the middle, under the touch plate):


White flashing slowly Starting up
White solid Connected to network, ready for use
Blue solid When not configured to network and not in configuration mode
Amber flashing fast Ready for network setup. Soft AP / WAC mode.
Amber flashing slowly Connecting to the network
Amber solid Wireless connection of medium quality
Red solid Wireless connection of poor quality
Red flashing fast Failed to connect to a wireless network

Status LED and lens LED simultaneously

Red, one flash Factory reset
Red flashing slowly Updating software
