Can I connect my Beolab 50 or subwoofers to non-Bang & Olufsen products?


Yes, you can connect your Bang & Olufsen speakers or subwoofers to non-Bang & Olufsen products.

The speakers/subwoofers must be connected to the line output (volume controlled line out) of the amplifier. Different kinds of cables are required depending on the type of sockets on your speaker/subwoofer, see the table below. The cables are available from your Bang & Olufsen retailer. You can find your nearest retailer here

If there is no Line-in connection on the speakers/subwoofers, and a Power Link is required, then use a Line/Power Link adaptor cable.

Loudspeaker Sockets
Beolab 11 Power Link
Beolab 5 Phono / RCA / Cinch
Beolab 9 Power Link
Beolab 8002 Phono / RCA / Cinch
Beolab 6002 Phono / RCA / Cinch
Beolab 3 Power Link
Beolab 4000 Power Link
Beolab 4 Mini-jack
Beolab 2 Line adaptor
Beolab 12 Power Link
Beolab 10 Power Link
Beolab 14 Power Link
Beolab 15 Power Link
Beolab 16 Power Link
Beolab 17 RCA (R-input-L) / Optical
Beolab 18 RCA (R-input-L) / Optical
Beolab 19 RCA (R-input-L)
Beolab 20 RCA (R-input-L) / Optical
Beolab 50 RCA (R-input-L) (2 x RCA)
Optical
S/P-DIF (1 x RCA)
USB-B Audio
Beolab 90 RCA (R-input-L) (2 x RCA)
Optical
S/P-DIF (1 x RCA)
USB-B Audio
XLR

You can also connect Bang & Olufsen passive speakers to non-Bang & Olufsen products. This type of speaker needs to be connected to any standard power amplifier output.

Loudspeaker Sockets
BeoVox 1 Speaker terminal
BeoVox 2 Speaker terminal
