The meaning of the indicator light on Beoplay EQ in charging mode is described in the table below.
Charging indicator without earphones in the charging case |
|
|
Orange (pulsing) |
Charging case charging |
|
Green (solid) |
Charging case fully charged |
|
Red (flashing) |
Charging case overheating. |
Charging indicator with earphones stored in the charging case |
|
|
Orange (flashing) |
Charging case and earphones charging |
|
Green (pulsing) |
Earphones fully charged, and charging case charging |
|
Orange (pulsing) |
Charging case fully charged, and earphones still charging |
|
Green (solid) |
Case and earphones fully charged |
| Red (flashing) |
Charging case is overheating. |
The meaning of the light indicator on Beoplay EQ not in charging mode is described in the table below.
Open charging case with earphones in charging case |
|
|
Orange (pulsing) |
Earphones charging |
|
Green (solid, 5 seconds) |
Earphones fully charged |
|
Blue (flashing) |
Bluetooth pairing mode |
|
Blue (solid) |
Bluetooth pairing successful |
|
Red (solid, 5 seconds) |
Bluetooth pairing failed |
|
Red (flashing, 5 times) |
Factory reset (completed after 20 sec. and the case flashing 5 times) |
|
Green (pulsing) |
Charging case software update in progress. Switches off when update is complete. |
Open charging case without earphones in case |
|
|
Green (solid, 5 seconds) |
The charging case has more than one full charge |
|
Orange (solid, 5 seconds) |
The charging case has less than one full charge |
|
Red (solid, 5 seconds) |
The charging case has very low battery. Charge the case now |
