Beocom Portal have two light indicators; one showing the status of headphones and one showing the status of the battery:
|
Product indicator (next to the Power/Bluetooth button) |
|
|
White |
|
|
- Solid |
Switched on |
|
- Flashing once |
Switching off (manually or automatically after no signal for 15 minutes*) |
|
Blue |
|
|
- Solid (5 seconds) |
Bluetooth connected |
|
- Flashing |
Bluetooth pairing mode (ready to pair with a device) |
|
Red |
|
|
- Solid (5 seconds) |
Bluetooth pairing failed |
|
- Solid |
Microphone muted |
|
- Flashing (5 seconds) |
Factory reset |
|
Green |
|
|
- Pulsing |
Software update ongoing |
* Can be disabled in the Bang & Olufsen app
|
Battery indicator |
|
|
Orange |
|
|
- Flashing |
Battery charging |
|
Green |
|
|
- Solid |
Charging complete |
|
Red |
|
|
- Flashing |
Charging error |
|
- Solid |
Battery low (2 - 10% charge) |
|
- Flashing |
Battery critically low (below 1% charge) |
